Casambi 65W 2CH NFC Enabled LED Driver (Constant Current) SRP-CS9105N-65CCT500-1500 Sunricher

SRP-CS9105N-65CCT500-1500 is a plastic casing 65W Bluetooth NFC programmable LED driver, enabled by Casambi technology. It is designed with 2 channels constant current output with adjustable current from 500mA to 1500mA, which enables it to be suitable for LED lights with different current. It is designed with 220-240VAC input with high Power factor and efficiency. It enables smooth and deep dimming to 0.01% without flickering and buzzing noise.

Key Features

• Casambi dimmable LED driver, works with Casambi network
• 2 channels dimmable LED driver. Max. output power 65W
• 500-1500mA current selectable via NFC program tool. Min.current gear lower to 0.1mA
• Class Ⅱ power supply, full isolated plastic case
• High power factor and efficiency
• ON/OFF, Dimming and Tunable White control
• Amplitude/CCR dimming, smooth and deep dimming
• IP20 rating, suitable for indoor LED lighting applications
• 5 years warranty

Specifications

Wiring Diagram
